Fully-Automatic

AcuReel 300

Roll to Roll Fully-Automatic

AcuReel是一款适用于300mm板宽的单面和双面卷对卷UV曝光机。

高解析、高对位精度和高产能是AcuReel的亮点。



主要特点
制程应用 内层,外层/防焊(有保护膜收放系统)/ PSR
曝光面积 最大300 x 650mm | 11.8” x 25.6”
解析度 15µm/15µm |0.6mil/0.6mil (线宽线距)
阻焊桥最小可达 50µm | 2mi
光源 LedLight™(LED光源)
ColliLight™ 5kW & 8kW (5KW,8KW的平行光)
'板厚 可达15μm/0.6mils
'光源 LED光源
LedLight™
'平行半角 ≤ 1.6°
'干膜光阻 适用于各种类型的干膜
'防焊(有保护膜收放系统)/PSR 适用于各种类型的油墨:绿色,白色,蓝色,红色,黑色…
'曝光模式 双面或单面
'对位精度 ±5μm | 0.2mil 底片/底片 (真空后)
±8μm | 0.32mil 底片/基板 (真空后)
±3μm | 0.12mil 重复对位精度 (真空后)
'CCD摄像头 内层制程和外层制程配置4个CCD摄像头
防焊(有保护膜收放系统) /PSR配置4+4个CCD摄像头
'产能 每天高达8000片
'料号更换 更换底片和参数设置≤ 5 分钟
'设备机壳 不锈钢机壳
'软件 采用17”触控屏Altix Suite人机界面
'空气净化 采用Hepa filter class 100高效过滤器
'板厚 可达15μm/0.6mils
'光源 LED光源 LedLight™
Collilight
'平行半角 ≤ 1.6°
'干膜光阻 适用于各种类型的干膜
'防焊(有保护膜收放系统) /PSR 适用于各种类型的油墨:绿色,白色,蓝色,红色,黑色…
'曝光模式 双面或单面
'对位精度 ±5μm | 0.2mil 底片/底片 (真空后)
±8μm | 0.32mil 底片/基板 (真空后)
±3μm | 0.12mil 重复对位精度 (真空后)
'CCD摄像头 内层制程和外层制程配置4个CCD摄像头
防焊(有保护膜收放系统) /PSR配置4+4个CCD摄像头
'产能 每天高达8000片
'料号更换 更换底片和参数设置≤ 5 分钟
'设备机壳 不锈钢机壳
'软件 采用17”触控屏Altix Suite人机界面
'空气净化 采用Hepa filter class 100高效过滤器
'语言 英语,简体中文,繁体中文,韩文,德文,法文…
'制程应用 内层,外层,防焊/ PSR
'曝光面积 最大 300 x 650mm | 11.8” x 25.6”
'解析度 15µm/15µm |0.6mil/0.6mil (线宽线距)
阻焊桥最小可达 50µm | 2mi
'光源 LedLight™(LED光源)
5KW,8KW的平行光

更多信息

Acura

Panel / Sheet Fully-Automatic

Acura是一款单面和双面兼用的全自动UV曝光机,配有不同的光源,包含LED光源,适用于内层,外层和防焊制程的高品质解析

主要特点
制程应用 内层,外层/防焊/ PSR
曝光面积 可达 610mm x762mm|24” x 30”
解析度 15µm/15µm|0.6mil/0.6mil (线宽/线距)
阻焊桥最小可达60µm|2.4mi
光源 LedLight™
平行光5KW,8KW
准直光
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine LED Light source
LedLight™
'Collimation ≤ 1.6°
'Dry Film Resist & Liquid ink For all types of dry film & liquid ink
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine High pressure mercury lamp
ColliLight™ 5kW & 8kW
'Collimation ≤ 1.5°
'Dry Film Resist & Liquid ink For all types of dry film & liquid ink
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine High pressure mercury lamp
OptiLight™
'Collimation <10°
'Liquid ink For all types of liquid ink
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine LED Light source
LedLight™
'Collimation ≤ 1.6°
'Dry Film Resist & Liquid ink For all types of dry film & liquid ink
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine High pressure mercury lamp
ColliLight™ 5kW
'Collimation ≤ 1.5°
'Dry Film Resist For all types of dry film
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine LED Light source
LedLight™
'Collimation ≤ 1.6°
'Dry Film Resist For all types of dry film
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 4 cameras
'Throughput Up to 4.5 panels/minute (dry film)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine High pressure mercury lamp
ColliLight™ 8kW
'Collimation ≤ 1.5°
'Dry Film Resist For all types of dry film
'Soldermask / PSR For all types of solder resist: green, white, blue, red, black…
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±10μm | 0.4mil AW/Panel (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 8 cameras
'Throughput Up to 3 panels/minute depending on SM ink (mJ)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Panel Thickness 0.05mm to 6mm | 0.002” to 0.236”
'Light Engine High pressure mercury lamp
OptiLight™
'Collimation <10°
'Dry Film Resist For all types of dry film
'Soldermask / PSR For all types of solder resist: green, white, blue, red, black…
'Exposure Method Double side
'Exposure Contact Soft or hard contact vacuum - CMI™
'Alignment ±5μm | 0.2mil AW/AW (after vacuum)
±10μm | 0.4mil AW/Panel (after vacuum)
±3μm | 0.12mil Repeatability (after vacuum)
'CCD Cameras 8 cameras
'Throughput Up to 3 panels/minute depending on SM ink (mJ)
'Batch Changeover < 2 minutes - Artwork change and cleaning, job setting update
'Construction Stainless steel
'Software Altix Suite with 17” touch screen
'Air Cleanliness Hepa filter class 100
'Languages English, Simplified & Traditional Chinese, Korean, German, French…
'Process Inner Layers & Outer Layers
'Exposure Area Up to 610mm x 762mm | Up to 24” x 30”
'Resolution Dry film: 15µm/15µm | 0.6mil/0.6mil (Line & Space)
'Light Engine LedLight™
ColliLight™ 5kW & 8kW

更多信息

Adix PT / F

Panel / Sheet Fully-Automatic

Adix SA 可以连接进出料+翻板系统,形成自动化生产模式。

Adix PT/F是一款基于其ALDS-Power4+™新技术的UV LED DMD直接成像解决方案,每个成像头包含4个不同的LED(4个不同波长)。

主要特点
全自动直接成像系统
最大610 x 610mm /单面10秒
内联或独立解决方案/并排通过或翻转双面生产
轻松应对多料号,少量多样生产模式
适用于各类型干膜,防焊油墨/PSR
'板厚 0.04mm 到 6mm
'光源 ALDS-Power4+™
'边缘粗糙度 ± 1,5µm
'景深 ± 100µm
'自动对焦 每个成像头配动态AF传感器,行程±2mm
'对位精度 ±12μm (层间对位精准度)
±8μm 片对板(孔或pad)
'CCD摄像头 3个CCD摄像头:层间对位精度
2个CCD摄像头: 片对板对位精度
1个CCD摄像头-成像校准
' 全自动直接成像系统
' 最大610 x 610mm /单面10秒
' 内联或独立解决方案/并排通过或翻转双面生产
' 轻松应对多料号,少量多样生产模式
' 适用于各类型干膜,防焊油墨/PSR

更多信息

Adix CS / F

Panel / Sheet Fully-Automatic

Adix CS/F 是一款具有收放板装置的直接成像系统。该连线系统在放板位置有一个可用于连接放板/收板的L型架的端口.



主要特点
可达 610 x 610mm /10秒完成单面曝光
A面 – B面模式:连续完成A面,利用暂存机构存放,再开始B面曝光作业
轻松应对多料号,少量多样生产模式
适用于各类型干膜和防焊油墨
'板厚 0.05mm ~ 3.2mm ( 5mm可选)
'产能 单面25秒
'传感器 集成智能双板侦测
集成(滑板)侦测
'双面 翻转台面两个手臂交换面板
' Adix SA can be incorporated with " Compact Automation " allowing full automatic operation
' 可达 610 x 610mm /10秒完成单面曝光
' A面 – B面模式:连续完成A面,利用暂存机构存放,再开始B面曝光作业
r
' 轻松应对多料号,少量多样生产模式
' 适用于各类型干膜和防焊油墨

更多信息

AcuReel 550

Roll to Roll Fully-Automatic

AcuReel是一款适用于550mm宽幅的单面和双面卷对卷UV曝光机。

高解析、高对位精度和高产能是AcuReel的亮点

主要特点
制程应用 内层,外层/防焊(有保护膜收放系统) / PSR
曝光面积 最大550 x 650mm | 21.6” x 25.6”
解析度 干膜 : 15µm/15µm |0.6mil/0.6mil (线宽线距)
阻焊桥最小可达 50µm | 2mi
光源 LedLight™(LED光源)
ColliLight™ 5kW & 8kW (5KW,8KW的平行光)
'板厚 可达15µm | 0. 6mil
'光源 LED光源
Collilight ™平行光
'平行半角 ≤ 1.6°
'干膜光阻 适用于各种类型的干膜
'防焊/PSR/片对卷 适用于各种类型的油墨:绿色,白色,蓝色,红色,黑色…
'曝光模式 双面或单面
'对位精度 ±5μm | 0.2mil 底片/底片 (真空后)
±8μm | 0.32mil 底片/基板 (真空后)
±3μm | 0.12mil 重复对位精度 (真空后)
'CCD摄像头 内层制程和外层制程配置4个CCD摄像头
防焊(有保护膜收放系统) /PSR配置4+4个CCD摄像头
'产能 每天高达8000片
'料号更换 5分钟内完成更换底片,清洁和参数设置
'空气净化 采用Hepa filter class 100高效过滤器
'板厚 可达15µm | 0. 6mil
'光源 LedLight™平行光
'平行半角 ≤ 1.6°
'干膜光阻 适用于各种类型的干膜
'防焊/PSR/片对卷 适用于各种类型的油墨:绿色,白色,蓝色,红色,黑色…
'曝光模式 双面或单面
'对位精度 ±5μm | 0.2mil 底片/底片 (真空后)
±8μm | 0.32mil 底片/基板 (真空后)
±3μm | 0.12mil 重复对位精度 (真空后)
'CCD摄像头 内层制程和外层制程配置4个CCD摄像头
防焊(有保护膜收放系统) /PSR配置4+4个CCD摄像头
'产能 每天高达8000片
'料号更换 5分钟内完成更换底片,清洁和参数设置
'空气净化 采用Hepa filter class 100高效过滤器
'
'制程应用 内层,外层,防焊/ PSR
'曝光面积 最大 550mm x 650mm | 21.6” x 25.6”

'解析度 15µm/15µm |0.6mil/0.6mil (线宽线距)
阻焊桥最小可达 50µm | 2mi
'光源 LedLight™(LED光源)
5KW,8KW的平行光

更多信息

Adix RtR

Roll to Roll Fully-Automatic

Adix卷对卷是专为单面卷对卷曝光系统设计的一个全自动直接成像设备,具备高解析、高对位精度和高产能的特点。

主要特点
制程应用 内层,外层/防焊(有保护膜收放系统)/ PSR
曝光面积 最大610 x 685mm |24” x 30”
解析度 干膜 : 20µm/20µm |0.8mil/0.8mil (线宽,线距)
阻焊桥最小可达 25µm | 1mi
光源 ALDS-Power4+™ 极短的数据预处理时间
每个成像头配置4个高功率 UV –LED光源
'板厚 30µm 到 500µm
'光源 ALDS-Power4+™
'边缘粗糙度 ±1,5µm | ±0.05mil
'景深 ±100µm
'自动对焦 每个成像头配动态自动对焦传感器,行程 ±8mm
'曝光光谱 从355nm到405nm
'对位精度 ±8μm | 0.3mil (对位精准度)
'CCD摄像头 影像对位:2+5个摄像头
影像校准:1个摄像头
'产能 30mJ/cm² 曝光能量为基准, 成像头Power4+, LLS25 RLT V2
(宽610mm x (长) 610mm 成像尺寸, 用 6 个成像头 (2): 2 面/分
(宽)610mm x (长) 305mm 成像尺寸,用 6 个成像头 (2): 3面/分
'收放卷 自动真空台面根据板尺寸,夹板机构
自动调节板牵引装置
板子手动靠边放置

更多信息
